4 in 1 handheld welding machine fiber laser cutter laser rust removal portable weld bead cleaning machine

4 in 1 handheld welding machine fiber laser cutter laser rust removal portable weld bead cleaning machine


4 in 1 handheld welding machine fiber laser cutter rust removal portable weld bead cleaning machine



Automatic laser welder with wire feeder Handheld laser welding machine 1000W 1500W 2000W 3000W cutter with perfect welding seam


4-in-1 Water Cooled Handheld Laser Welding Machine with 4 functions - welding cutting, rust removal and weld bead cleaning.


Laser welding machine can be widely used in metal equipment, stainless steel Kitchen and other industries complex irregular welding process.
Its advantages are simple operation, welding seam beautiful, fast welding speed and no consumables. Welding in thin stainless steel plate, iron plate, aluminum plate and other metal materials can perfectly replace the traditional argon arc welding and electric welding technology.

handheld laser welder.jpg  1682081744189.png


Handheld Fiber Laser Welding Machine is a new type high-power, high-end continuous welding tool which adopts a high-quality fiber laser source to produce a fiber optic beam. After transmission processing, the light is focused on the workpiece to achieve continuous welding. It avoids the two thresholds of thermal strain and post-treatment, and is environmentally friendly and pollution-free, greatly improving the joint strength and quality of welding.


4 in 1 laser welding machine.jpg laser welding machine 1.jpg


Model

ES1000

ES1500

ES2000

ES3000

Laser Power

1000watt

1500watt

2000watt

3000watt

Laser Source

Fiber Laser Manufactured by Raycus Max JPT

Wavelength(nm)

1064 - 1080

Laser Mode

Continues / Pulsed

Beam Quality

M2<1.2

M2<1.2

M2<1.5

M2<1.5

Length of Fiber

5-10m (customized)

Interface

QBH

Welding Width

0.2-5mm (adjustable)

Laser Preview

Integrated Red Light Preview

Cooling

Integrated Water Chiller

Language

Chinese / English / Russian / Korean / Vietnamese

Power Supply

AC 220V, 50Hz/60Hz

AC 380V, 50Hz/60Hz

Security System

TSS - Trip Security System Available

Parameter Setting

Touch Panel

Welding Materials

Carbon Steel, Stainless Steel, Aluminum, Brass, Alloy etc.

Welding Speed

0-120mm/s (adjustable)




The fiber laser welding machine for sale is an affordable, easy-to-use, and versatile tool that can help you begin a new start-up venture or increase the profits of your well-established company. This type of fiber laser welder is suitable for welding stainless steel, carbon steel, alloy steel, spring steel, copper plate, aluminum plate, gold, silver, titanium ect., and has been widely used in advertising, high pressure / low voltage electrical cabinet production, textile machinery accessories, kitchen appliances, cars, machinery, elevators, electrical accessories, spring coil pieces, metro line parts and other industries.
